Suitable for: all kinds of square box single, two-sided diagonal sealing and labeling, provide complete box, top pressure fixed, labeling, corner Fu standard and labeling to detect and eliminate leakage etc. function to ensure sealing and labeling intact, users can be assured and cartoning machine high-speed connections use.

[to be completed four sealing and labeling (surface sealing and labeling, surface sealing and labeling, two diagonal sealing and labeling) [pressing device, ensure that the labeling kit stability, greatly improve the labeling accuracy, of small light box is especially suitable for [reserved input / output signal and interface, online can accept PC control signal, matched with the production line linkage convenient production line overall management of the following optional unqualified products automatic removing function of the following optional transparent protecting cover, are equipped with a safety lock switch to ensure the safety of the operator (1688-1744) printing equipment: flexible selecting thermal hot printer or printer configuration, the synchronization is complete code, and labeling

Box size: highly 20-100mm, width 90-210mm labeling speed: 80-120 box / minutes (with box and label size related) labeling accuracy: 1.0mm (regardless of the packaging and label error) working pressure: 0.45-0.6Mpa (eliminating device for conveyor belt width: Standard 91mm (non standard production) power supply and power: 220VAC 5% 50Hz 1.0Kw machine size: (L) 2000 x (W) 900 x (H) 1300 mm
